| U2104B |
High voltage 600V，High current High-Side Half-Bridge Driver，With SD function2.2A/2.5A大電流，600V高壓使能半橋驅動 |
600V |
10~20 |
IN1+, SD-輸入高有效，使能低關閉 |
Y |
— |
2.0A/2.5A |
680&150ns |
520ns |
8.9-8.2 |
7.8-8.6 |
— |
— |
— |
|
SOP8 |
| U2104 |
High voltage 600V，High current High-Side Half-Bridge Driver，With SD function
2.2A/2.5A大電流，600V高壓使能半橋驅動
|
600V |
10~20 |
IN1+, SD+
輸入高有效，使能高關閉
|
Y |
— |
2.0A/2.5A |
680&150ns |
520ns |
8.9-8.2 |
7.8-8.6 |
— |
— |
— |
|
SOP8 |
| U2184 |
High voltage 600V，High current High-Side Half-Bridge Driver，With SD function2.2A/2.5A大電流，600V高壓使能半橋驅動 |
600V |
10~20 |
IN1+, SD+輸入高有效，使能高關閉 |
Y |
— |
2.0A/2.5A |
680&150ns |
520ns |
8.9-8.2 |
7.8-8.6 |
— |
— |
— |
|
SOP8 |
| U2104M |
High voltage 600V，High-Side Half-Bridge Bridge Driver，With SD function
600V高壓使能半橋驅動
|
600V |
10~20 |
IN1+, SD+
輸入高有效，使能高關閉
|
Y |
— |
0.4A/0.6A |
680&150ns |
520ns |
4.8-4.5 |
4.9-4.6 |
— |
— |
— |
|
SOP8 |
| U21276 |
High Voltage，High current High-Side driver IC，With OCP
高壓大電流4A/6A單路高邊驅動，帶過流保護功能
|
600V |
10~20 |
IN1+, FAULT-
高側高有效
|
— |
— |
4A/6A |
220&220ns |
— |
— |
6.4-6.3 |
— |
Y |
— |
— |
SOP8 |
| U21277 |
High Voltage，High current High-Side driver IC，With OCP
高壓大電流2A/4A單路高邊驅動，帶過流保護功能
|
600V |
10~20 |
IN1+, FAULT-
高側高有效
|
— |
— |
4A/6A |
220&220ns |
— |
— |
6.4-6.3 |
— |
Y |
— |
— |
SOP8 |
| U3215 |
High voltage 600V, High current Dual-Half Bridge Driver
2.2A/2.5A大電流高壓600V，雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN-
高側高有效，低側低有效
|
— |
Y |
2A/2.5A |
220&120ns |
100ns |
4.8-4.5 |
4.9-4.6 |
— |
— |
— |
— |
SOP8 |
| U3216 |
High voltage 600V, High current Dual-Half Bridge Driver
2.1A/2.6A大電流高壓600V，雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
2A/2.5A |
220&120ns |
100ns |
4.8-4.5 |
4.9-4.6 |
— |
— |
— |
— |
SOP8 |
| U3215C |
High voltage 600V, High current Dual-Half Bridge Driver
2.1A/2.6A大電流高壓600V，雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN-
高側高有效，低側低有效
|
— |
Y |
2A/2.5A |
320&200ns |
120ns |
4.8-4.5 |
4.8-4.5 |
— |
— |
— |
— |
SOP8 |
| U3216C |
High voltage 600V, High current Dual-Half Bridge Driver2.5A/2.7A
大電流高壓600V，雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
2A/2.5A |
320&100ns |
120ns |
4.8-4.5 |
4.9-4.6 |
— |
— |
— |
— |
SOP8 |
| U2106 |
High voltage 600V, Low current Dual-Half Bridge Driver
小電流高壓600V，雙路半橋驅動芯片
|
600V |
9~21 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
0.5/0.8A |
320&260ns |
50ns |
8.5-7.9 |
8.4-7.8 |
— |
— |
— |
— |
SOP8 |
| U2103C |
High voltage 600V, Low current Dual-Half Bridge，Built-in Bootstrap Diode
高壓600V小電流內置自舉二極管雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
0.4/0.6A |
420&200ns |
220ns |
4.7-4.5 |
4.7-4.5 |
— |
— |
— |
— |
SOP8 |
| U2106C |
High voltage 600V, Low current Dual-Half Bridge，Built-in Bootstrap Diode
高壓600V小電流內置自舉二極管雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
0.4/0.6A |
420&200ns |
220ns |
4.7-4.5 |
4.7-4.5 |
— |
— |
— |
— |
SOP8 |
| U2304C |
High voltage 600V, Low current Dual-Half Bridge，Built-in Bootstrap Diode
高壓600V小電流內置自舉二極管雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
0.1/0.16A |
420&200ns |
220ns |
4.7-4.5 |
4.7-4.5 |
— |
— |
— |
— |
SOP8 |
| U2181C |
High voltage 600V, High current Dual-Half Bridge Driver
2.2A/2.5A大電流高壓600V，雙路半橋驅動芯片
|
600V |
5~20 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
— |
2A/2.5A |
200&180ns |
— |
4.8-4.5 |
4.9-4.6 |
— |
— |
— |
— |
SOP8 |
| UNI2181 |
Dual-Half Bridge
雙路半橋驅動芯片
|
600V |
9~21 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
— |
2.2A/2.7A |
540&120ns |
420ns |
8.6-8.0 |
8.5-7.9 |
— |
— |
— |
— |
SOP8 |
| U2183 |
High voltage 600V, High current Dual-Half Bridge Driver
2.2A/2.5A大電流高壓600V，雙路半橋驅動芯片
|
600V |
9~21 |
HIN+, LIN+
高側高有效，低側高有效
|
— |
Y |
2.2A/2.7A |
540&120ns |
420ns |
6.8-6.2 |
6.6-6.0 |
— |
— |
— |
— |
SOP8 |
| U21867 |
Dual-Half Bridge雙路半橋驅動芯片 |
600V |
9~21 |
HIN+, LIN-高側高有效，低側低有效 |
— |
— |
5A/6A |
540&120ns |
420ns |
8.6-8.0 |
8.5-7.9 |
|
|
|
|
SOP8 |
| U21868 |
Single-low-side driver，With ICS,FARLT function雙路半橋帶限流，錯誤報警功能驅動 |
600V |
9~21 |
HIN+, LIN+,ICS,FARLT高側高有效，低側低有效 |
— |
— |
5A/6A |
540&120ns |
420ns |
8.6-8.0 |
8.5-7.9 |
|
|
|
|
SOP16 |
| UNI2113S |
High voltage 600V, High current Dual-Half Bridge Driver,With SD function
2.5A/2.7A大電流高壓600V，雙路半橋驅動芯片，帶SD使能
|
600V |
10~20 |
HIN+, LIN-,SD+
高側高有效，低側高有效,SD高關閉
|
Y |
Y |
2.0A/2.5A |
160&132ns |
110ns |
8.8-8.2 |
8.8-8.2 |
— |
— |
— |
|
SOP-16(W) |
| UNI2113P |
High voltage 600V, High current Dual-Half Bridge Driver,With SD function
2.5A/2.7A大電流高壓600V，雙路半橋驅動芯片，帶SD使能
|
600V |
10~20 |
HIN+, LIN-,SD+
高側高有效，低側高有效,SD高關閉
|
Y |
Y |
2.0A/2.5A |
160&132ns |
110ns |
8.8-8.2 |
8.8-8.2 |
— |
— |
— |
|
DIP-14 |
| UNI2113C |
High voltage 600V, High current Dual-Half Bridge Driver,With SD function
2.5A/2.7A大電流高壓600V，雙路半橋驅動芯片,帶SD使能
|
600V |
10~20 |
HIN+, LIN+,SD+
高側高有效，低側高有效，SD高關閉
|
Y |
Y |
2.0A/2.5A |
160&132ns |
110ns |
8.8-8.2 |
8.8-8.2 |
— |
— |
— |
|
QFN16 |
| U4315 |
Six-Full Bridge
三相六路全橋驅動
|
600V |
10~20 |
HIN1+/HIN2+/HIN3+, LIN1-/LIN2-/LIN3-
三路高側高有效，三路低側低有效
|
Y |
Y |
0.25/0.4A |
420&210ns |
200ns |
8.9-8.3 |
8.9-8.3 |
— |
Y |
— |
— |
SOP28(W) |
| U4316 |
Six-Full Bridge
三相六路全橋驅動
|
600V |
10~20 |
HIN1+/HIN2+/HIN3+, LIN1-/LIN2-/LIN3-
三路高側高有效，三路低側低有效
|
Y |
Y |
0.25/0.4A |
420&210ns |
200ns |
8.9-8.3 |
8.9-8.3 |
— |
Y |
— |
— |
SOP28(W) |
| U4316S |
Six-Full Bridge，Built-in Bootstrap Diode
三相六路全橋驅動，內置自舉二極管
|
600V |
10~20 |
HIN1+/HIN2+/HIN3+, LIN1-/LIN2-/LIN3-
三路高側高有效，三路低側低有效
|
Y |
Y |
0.25/0.4A |
420&210ns |
200ns |
8.9-8.3 |
8.9-8.3 |
Y |
Y |
— |
— |
SOP28(W) |
